Variable Displacement
11%
- Introducing the P16V-RSTU-30-CMC-21-J (N5.5) piston pump from Tokyo Keiki (formerly Tokimec), redesigned to offer lower noise levels by an average of 5dB (as compared to older designs).
- With a body that is 60mm (2.3 inches) narrower the weight has been reduced by almost 9 lbs all while maintaining the same connection points.
- Direct replacement for models P16VMR-10-CMC-20-S121-Jand P16V-RSG-11-CMC-10-S121-J
- Simplifies Hydraulic Circuits: Equipped with a pressure compensator, the P16V-30 series eliminates the need for relief valves, streamlining hydraulic circuits and increasing overall efficiency.
- Our specialized cylinder bore surface treatment enhances pump life and ensures stable operation even in challenging environments with contamination risks.
- Swash plate design
- Flange mounting (Foot bracket option)
- Right (R) or left (L) rotation
- Single side displacement
- SAE O-ring seal (G option)
- Various control options
- Maximum Displacement Adjustment (*C)
20%
- Choose between standard hydraulic fluid (Mineral Oil) or Water Glycol (F11)
- Mounting bracket (F) is available for mounting flexibility & stability
- Maximum Displacement: 70cm³/rev (33.3 GPM)
- Maximum Operating Pressure: 21MPa (3,050psi)
- Speed Range: 600-1800 (rpm)
- Rotation: Right-hand (R) & Left-Hand (L) Rotations available for flexibility
- Max Displacement Customization
20%
- Choose between standard hydraulic fluid (Mineral Oil) or Water Glycol (F11)
- Mounting bracket (F) is available for mounting flexibility & stability
- Maximum Displacement: 31cm³/rev (14.7 GPM)
- Maximum Operating Pressure: 21MPa (3,050psi)
- Speed Range: 600-1800 (rpm)
- Rotation: Right-hand (R) & Left-Hand (L) Rotations available for flexibility
- Max Displacement Customization
- Variable Displacement Piston Pump Load Sensing Type
- Energy-saving load-sensing control ensures optimal performance and efficiency.
- Geometric displacement options: 16.3–180.7 cm³/rev.
- High operating pressure: Rated 31.5 MPa; Intermittent 35 MPa.
- Four control modes: Pressure compensator, pilot pressure compensator, constant power, load sensing.
- Through-drive system supports additional pumps for flexible setups.
- Wide shaft speed range: 600–3600 r/min.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
- Piston Pump Constant power Type with External Pilot
- Handles high-pressure (31.5 MPa rated) and wide flow ranges (16–125 cm³/rev).
- Dual-functionality: Manages low-pressure/high-flow and high-pressure/low-flow tasks.
- Features constant power control for efficiency and adaptability.
- Compatible with JIS, ISO 3019-2, and SAE J744 mountings.
- Geometric Displacement Options: 37.1 to 180.7 cm³/rev.
- Shaft Speed: 600–2700 r/min; keyed and spline shaft variants.
- Advanced controls: pressure compensator, load sensing, and remote pressure adjustment.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
- Piston Pump Constant power Type with External Pilot
- Handles high-pressure (31.5 MPa rated) and wide flow ranges (16–125 cm³/rev).
- Dual-functionality: Manages low-pressure/high-flow and high-pressure/low-flow tasks.
- Features constant power control for efficiency and adaptability.
- Compatible with JIS, ISO 3019-2, and SAE J744 mountings.
- Geometric Displacement Options: 37.1 to 180.7 cm³/rev.
- Shaft Speed: 600–2700 r/min; keyed and spline shaft variants.
- Advanced controls: pressure compensator, load sensing, and remote pressure adjustment.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
- Piston Pump Constant power Type with External Pilot
- Handles high-pressure (31.5 MPa rated) and wide flow ranges (16–125 cm³/rev).
- Dual-functionality: Manages low-pressure/high-flow and high-pressure/low-flow tasks.
- Features constant power control for efficiency and adaptability.
- Compatible with JIS, ISO 3019-2, and SAE J744 mountings.
- Geometric Displacement Options: 37.1 to 180.7 cm³/rev.
- Shaft Speed: 600–2700 r/min; keyed and spline shaft variants.
- Advanced controls: pressure compensator, load sensing, and remote pressure adjustment.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
- Piston Pump Constant power Type with External Pilot
- Handles high-pressure (31.5 MPa rated) and wide flow ranges (16–125 cm³/rev).
- Dual-functionality: Manages low-pressure/high-flow and high-pressure/low-flow tasks.
- Features constant power control for efficiency and adaptability.
- Compatible with JIS, ISO 3019-2, and SAE J744 mountings.
- Geometric Displacement Options: 37.1 to 180.7 cm³/rev.
- Shaft Speed: 600–2700 r/min; keyed and spline shaft variants.
- Advanced controls: pressure compensator, load sensing, and remote pressure adjustment.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
- Piston Pump Constant power Type with External Pilot
- Handles high-pressure (31.5 MPa rated) and wide flow ranges (16–125 cm³/rev).
- Dual-functionality: Manages low-pressure/high-flow and high-pressure/low-flow tasks.
- Features constant power control for efficiency and adaptability.
- Compatible with JIS, ISO 3019-2, and SAE J744 mountings.
- Geometric Displacement Options: 37.1 to 180.7 cm³/rev.
- Shaft Speed: 600–2700 r/min; keyed and spline shaft variants.
- Advanced controls: pressure compensator, load sensing, and remote pressure adjustment.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please get in touch with us to explore additional options.
