AR16-FR01B-22 | Variable Displacement Piston Pump

The Yuken AR Series hydraulic pumps are renowned for their compact design and high performance, making them ideal for a wide range of hydraulic applications. With options like the AR16 and AR22 models, these pumps deliver precision, durability, and energy efficiency. The series is designed to meet the demands of industrial machinery, offering flexible mounting options, reliable pressure adjustment, and extended operational lifespan.

Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please contact us to explore additional options.

Key Features:

• Compact Design: Easy to integrate into tight spaces without compromising on performance.
• Energy Efficiency: Adjustable flow and pressure settings for optimal energy use.
• Durable Construction: Built to endure heavy-duty operations in various industrial environments.

Specifications:

• Geometric Displacement: 15.8 cm³/rev (AR16), 22.2 cm³/rev (AR22)
• Min. Adjustable Flow: 6.0 cm³/rev (AR16), 8.5 cm³/rev (AR22)
• Operating Pressure: Rated at 16 MPa (intermittent)
• Shaft Speed Range: 600 – 1800 r/min
• Mounting: Flange Mounting
• Direction of Rotation: Clockwise (viewed from shaft end)
• Port Position: Axial (None) or Side Port (S)
• Approx. Mass: 11.8 kg (AR16), 12.5 kg (AR22)

Optimize your hydraulic system with the Yuken AR Series for unparalleled performance and reliability.
