A16-F-R-01-H-K-32950 | Pressure Compensator Type Variable Displacement Piston Pump

Achieve precision and efficiency with Yuken's A Series Pressure Compensator Type Variable Displacement Piston Pump, designed to handle demanding industrial applications. With advanced pressure compensation technology, this pump ensures stable flow rates, reduced energy consumption, and reliable operation.

Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please contact us to explore additional options.

Key Features:

• Versatile Performance: Supports a range of geometric displacements, from 10.0 cm³/rev to 145 cm³/rev.
• Pressure Range: Operating pressure rated at 16-21 MPa, with intermittent pressures reaching 16-21 MPa.
• Adaptable Shaft Speed: Maximum shaft speed of 1800 rpm, suitable for diverse applications.
• Wide Fluid Compatibility: Handles water-glycols, phosphate esters, and polyol ester types.
• Temperature Range: Operates efficiently between 0°C to 60°C.

Specifications:

• Minimum adjustable flow: 2 to 83 cm³/rev.
• Shaft speed range: 600–1800 rpm.
• Available mounting: Flange or foot mounting options.
• Flexible port position: Axial or side ports available.

Perfect for hydraulic systems demanding high performance, this pump is engineered for reliability, efficiency, and ease of maintenance.
