A56-F-R-07-S-K-32950 | Pilot Pressure Control Type Pressure Compensator Piston Pump

Upgrade your hydraulic systems with Yuken's A Series Pilot Pressure Control Type Pressure Compensator Piston Pump. Designed for efficiency and durability, this pump delivers precise pressure regulation, ensuring optimal system performance. With its compact design, it fits seamlessly into various industrial applications.

Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please contact us to explore additional options.

Key Features:

• Available in different displacements (10.0 to 145.0 cm³/rev) for tailored performance.
• Operates with rated pressures up to 25 MPa, ensuring high reliability.
• Compact and lightweight with options for flange or foot mounting.
• Shaft speed up to 1800 r/min for dynamic operations.
• Built with Yuken’s renowned quality for long-lasting use.

Specifications:

• Displacements: A10 (10.0 cm³/rev), A70 (70.0 cm³/rev), A90 (91.0 cm³/rev), A145 (145.0 cm³/rev).
• Operating Pressure: Rated 25 MPa; intermittent 28 MPa.
• Speed Range: Max 1800 r/min, min 600 r/min.
• Mounting: Flange or foot options for versatile applications.
• Weight: From 8.5 kg (A10) to 119 kg (A145).

Achieve unmatched hydraulic efficiency and reliability with Yuken’s A Series Piston Pumps. Ideal for demanding industrial environments.
